FlacheSAN2V-UN 2U 48 BAYS 7MM 12G SAS/SATA SSD SINGLE EPYC 800W HRP
Key Features
- Flash server supports Single AMD EPYC up to 1TB DDR4
- Front hot-swap 48x 2.5” 7mm and 2 internal 2.5” 15mm for OS drives
- Up to 18GB/s (128Gbps) seq. read and up to 1.4M IOPS 4KB random read
- Supports up to 7x Low Profile MD2 PCIe Expansion slots
- High efficiency redundant power supplies
System
| Processor | Supports UP AMD EPYC (Naples) up to 180W TDP socket SP3 |
|---|---|
| System Memory | Supports 16x DDR4 ECC RDIMM/LRDIMM 2133/2400/2666 MT/s |
| Storage | 4x SlimSAS for 16 SATA 6G and 4x 6G/12G SAS HBA/RAID controllers by using available PCIe slots |
| Drive Bays | 48x front hot-swap 2.5" 7mm 6G SATA drive bays; 2x internal .5" 7 or 15mm 6G SATA bays |
| Cooling | 4x 80mm cooling fans |
I/O
| Expansion | Supports up to total of 7 PCIe slots; 3 PCIe3 x8; 4 PCIe3 x16 |
|---|
Environment
| Operating Temperature | 0°C ~ 35°C |
|---|---|
| Storage Temperature | -20°C ~ 70°C |
| Relative Humidity | 5% ~ 95% relative humidity, non-condensing |
| HTS Code | 8473 30 5100 |
| ECCN | 4A994 |
| Compliance | CE, FCC Class A, RoHS 6/6 compliant |
Physical
| Dimensions (W x H x D) | System: 26"x19"x3.5" (LxWxH) Packaging: 36"x 24.5"x10.5"(LxWxH) |
|---|---|
| Weights | Gross: 25KG/55LBS; Net: 21.36KG/46LBS |
Downloads
| Data Sheet | DS-FlacheSAN2V-UN |
|---|---|
| BIOS | BIOS Gigabyte MZ31-AR0 |
| Firmware | Firmware Gigabyte MZ31-AR0 |
| Product Brief | PB_FlacheStreams_AMD |
