FlacheSAN1L-UN 1U 20 Bays 7MM 12G SAS /SATA SSD Single EPYC
Key Features
- Storage server supports Single Socket Intel® Xeon® SP Skylake up to 768GB DDR4
- 2U with 20x hot-swappable 2.5”- 7mm SATA SSD or HDD bays
- Support 3x PCIe slots (2x Full Height)
- Low acoustic noise and induced vibrations for greater reliability
- Capable of sustaining up to 112Gbps of throughput and 1M+ IOPS
System
| Processor | Supports Single Socket AMD EPYC (Naples) CPU up to 180W TDP socket SP3 |
|---|---|
| System Memory | Supports up to 16x DIMMs DDR4 RDIMM/RDIMM/LRDIMM 2666 MHz |
| Network | 2x 1GbE Broadcom BCM5720 1x GbE dedicated for IPMI |
| Drive Bays | 20x 2.5" 7mm hot-swap 6Gbps SATA drive bays; 2x Internal 2.5" bays for OS drives |
| Cooling | 5x 40mm fans with Smart Fan Control |
I/O
| Expansion | 1x PCI-E 3.0 x16 OCP 2.0 Mezzanine 1x PCI-E 3.0 x16 Full Height 1x PCI-E 3.0 x16 Low Profile |
|---|
Environment
| Operating Temperature | 0°C ~ 35°C |
|---|---|
| Storage Temperature | -20°C ~ 70°C |
| Relative Humidity | 5% ~ 95% relative humidity, non-condensing |
| HTS Code | 8473 30 5100 |
| ECCN | 4A994 |
| Compliance | CE, FCC Class A, RoHS 6/6 compliant |
Physical
| Dimensions (W x H x D) | System: 27"x19"x1.75" (LxWxH) Packaging: 35"x 24.5"x9"(LxWxH) |
|---|---|
| Weights | Gross Weight: 47lbs without Hard Drives Net Weight: 35lbs without Hard Drive |
Downloads
| Data Sheet | DS-FlacheSAN1L-UN |
|---|---|
| BIOS | S8026_BMC S8026_v100 |
| Product Brief | PB_FlacheStreams_AMD |
